[TM E9-369A: German 88-mm Antiaircraft Gun Materiel]
TM E9-369A: German 88-mm Antiaircraft Gun Materiel
Technical Manual, War Department, June 29, 1943
[DISCLAIMER: The following text is taken from a WWII U.S. War Department Technical Manual. As with all manuals, the text may be incomplete or inaccurate. No attempt has been made to update or correct the contents of the original technical manual. Any views or opinions expressed do not necessarily represent those of the website.]


Chapter 1.  Introduction
 2.  German 88-mm Antiaircraft Gun and Mount
  I. Description and functioning of gun
  II. Description and functioning of recoil mechanism
  III. Description and functioning of mount
  IV. Operation
  V. Lubrication
  VI. Care and preservation
  VII. Inspection and adjustment
  VIII. Malfunctions and corrections
  IX. Disassembly and assembly
 3.  Ammunition
 4.  Sighting and Fire Control Equipment
   I. Introduction
   II. Sighting equipment
   III. Fire control equipment
 5.  Firing Tables
 6.  References
